Adopting Permanent motor oil-free scroll compressor head
Adopting Belt Driven oil-free scroll compressor head
Oil Free Scroll Air Compressor + Tank
Oil Free Scroll Air Compressor + Tank + Dryer
Oil Free Scroll Air Compressor + Tank + Membrane dryer
| MODEL NO. | RATED POWER kW(HP) | RATED SPEED rpm | PRESSURE MPa | CAPACITY L/min | AIR OUTLET | DIMENSION (L*W*H) mm | WEIGHT Kg |
| T SERIES(BELT POWER FREOUENCY AIR END) | |||||||
| T02T | 3.0/4 | 3000 | 0.8 | 300 | Rp3/8 | 408*330*292 | 16 |
| T03T | 2.2/3 | 3000 | 0.8 | 240 | Rp3/8 | 414*325*293 | 15 |
| T04T | 3.0/4 | 3000 | 0.4 | 440 | Rp3/8 | 345*289*263 | 16 |
| T05T | 3.7/5 | 3000 | 0.8 | 400 | Rp3/8 | 446*341*311 | 23 |
| T06T | 5.5/7.5 | 3000 | 0.8 | 600 | Rp3/8 | 445*496*354 | 29 |
| T07T | 5.5/7.5 | 2800 | 0.4 | 1000 | Rp3/4 | 434*406*365 | 30 |
 |
